Gtk 48V 50Ah 100AH 120Ah 150Ah 200Ah Lifepo4 Lithium Battery Bluetooth BMS For Solar System Hybrid Inverter 2000W 5000W 10KW

$483.00$1,400.00
In Stock
  • Delivered today (order Mon-Fri before 12:00, delivery between 17:00 and 22:00)
  • Including shipping costs, sent by blonwe.com
  • Pick up at a blonwe.com collection point is possible
  • 30 days to change your mind and free returns
  • Day and night customer service
SKU: FGVMD393F4EY

Description

Gtk 48V 50Ah 100AH 120Ah 150Ah 200Ah Lifepo4 Lithium Battery Bluetooth BMS For Solar System Hybrid Inverter 2000W 5000W 10KW +charger
Packing list:
1* 48V 50/80/100/150/200AH Lifepo4 Battery Pack with Case,with build-in BMS.
1* 58.4V 10A charger (100-200Ah) or 1* 58.4V 5A charger (50-80Ah)
Remark:
We offer lithium, lifepo4 and ni-mh battery, accept customized battery pack, we can’t update all items here. If any battery you want, please take it easy to contact with me tell me the capacity voltage and size you want, thanks.
No. Item Specification
1 Charge cut-off voltage DC 58.4V
2 Nominal voltage 48V
3 Nominal capacity 50/80/100/150/200AH
5 Charge current Standard charge: 0.2C Approx 6 Hour Rapid charge: 0.5C Approx 2.5 Hour
6 Standard Charging method 0.2 CC(constant current) charge to 58.4V, then CV(constant voltage 58.4V) charge till charge current decline to less than 0.02C
7 Max. charge current 50A
8 Max. discharge current 100A (50-120Ah item) /200A (150-200AH item)
9 Max.Pulse Current 200A/400A
10 Discharge cut-off voltage 40V
11 Cell 3.2V Lifepo4
12 Operating temperature Charging: 0°C – 45°C Discharging: -10°C- 60°C 13 Storage temperature -10°C to + 45°C
15 Battery Specification
50Ah : 340*230*300mm 16-20kg 100A BMS 4800W
80Ah : 340*230*380mm 22-26kg 100A BMS 4800W
100Ah : 340*230*380mm 35-39kg 100A BMS 4800W
120Ah : 340*230*520mm 36-40kg 100A BMS 4800W
150Ah : 380*210*550mm 42-46kg 200A BMS 4800W Max 10KW
200AH : 230*450*520mm 58-65kg 200A BMS Max 10KW
16 Battery outgoing voltage 58.4V-40V
17 BMS built in Yes
18 Life time Cycles:6000 times
BMS ( Battery Management System )
BMS is higher level PCM, which is safety control and management system to monitor battery status in order to make battery better working and lengthen battery life time objectively. BMS is mainly used in high capacity li-ion/li-polymer/lifepo4 battery packs. BMS is advanced integration of management, protection, communication and self-diagnose and cell balancing. Major functions:
1. Overcharge protection
2. Overdischarge protection
3. Overcurrent protection
4. Overheat protection(NTC)
5. Short circuit protection
6. Temperature sensing
7. Cell monitoring & balancing
8. Communication interface
9. Self-diagnose
10. Power gauge

Additional information

Weight 0.1 kg
Dimensions 1 × 1 × 1 cm
Rated voltage

48V

Hign-concerned Chemical

None

Nominal Capacity

50Ah 100AH 120Ah 150Ah 200Ah

Model Number

48v

Type

Lifepo4

Brand Name

GTK

Origin

Mainland China

Certification

CE
